Model 11 BH - Bridge Handle:

Actions / Downloads:

• Print

Fixing Type: Concealed - Machined female threads for fixing with screws from below.

Material: Chrome plated steel

Finish: Polished

Options: This product comes complete with nickel plated dress rings, screws and washers.

Please refer to the table below for types and sizes of this product. Once you have found the exact component you require, select the 'Quote' button. In the fields provided, enter the quantity you require and add any special options or non-standard colours / threads.
We will reply by email within one working day with a price and delivery schedule.

PATTERN	PART NO.	A	B	C	D	E	Thread size	QUOTE REQUEST
MBHS1	5436R	93	24	88	19	5	M3
MBHS2	5437U	96	33	88	25	8	M4
MBHS3	5438X	104	33	96	25	8	M4
MBHS4	5439P	128	33	120	31	8	M4
MBHS5	5440V	130	41	120	31	10	M5
MBHS6	5441Y	190	41	180	31	10	M5
MBHS7	5442Q	245	41	235	31	10	M5
