| Part No. | A | B | C | D | E | F | Hole Size (mm) | Download CAD | Stocked status | M.O.Q. | Typical lead time | Price & availability |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 14279P | 48 | 48 | 30 | 30 | 11 | 16 | 7 | CAD | Stocked | Minimum order is 2 pieces | Typical lead time is 2 days | Confirm price & availability |
| 14280W | 64 | 64 | 40 | 40 | 13 | 19 | 7 | CAD | Stocked | Minimum order is 2 pieces | Typical lead time is 2 days | Confirm price & availability |
Plastic Countersunk Hinge for Aluminium Profile Extrusions
Description
Our Model 03 HI plastic hinge is designed specifically for use with 30mm and 40mm aluminium profile extrusion however it also well suited to various other hinge applications.
The glass filled nylon body and zinc plated steel pin make for a low weight but strong and durable construction.
The 7mm countersunk bores are ideal for M6 threaded bolts or screws commonly used in conjunction with t-slots to create doors, panels and guards on furniture and equipment constructed from aluminium profile extrusions.
Material
High impact resistant thermoplastic
Colour
Black. Other RAL colours available (MOQs apply).
Download datasheetThis product complies with:
RoHS REACH Conflict Minerals California Prop 65
